Davey PRESSURE TANKS

Davey SuperCell steel tanks incorporate the latest internal designs for long tank life.

A range of capacities and pressures are available.
> Supercell steel shell tanks include the latest internal designs for long tank life

> P and G model Supercells have FDA approved captive diaphragms with virgin polypropylene
wetted area liners and patented stainless steel water inlets
> The exterior is finished in high quality polyurethane over an epoxy undercoat for years of reliable life
> The larger capacity G model Supercells also feature a patented controlled action diaphragm assembly
which provides a separation between diaphragm and tank walls, thus extending tank service life
> HP models for higher pressure applications

WHY CHOOSE THE DAVEY Supercell P Tanks?

Captive diaphragm held firmly in a central position:
• Less movement allowing use of a thicker reinforced diaphragm material than a bag or bladder tank for longer life

Heavy duty butyl diaphragm meets all major worldwide requirements for potable water applications:
• Safe, non-toxic

Safe potable grade virgin polypropylene liner seals the water from the tank shell:
• Longer life
• Specific wear areas reinforced for longer life

Deep drawn steel shell with appliance like 2 part polyurethane enamel finish and epoxy primer:
• Protected against rusting & the effects of UV light for long life

Patented stainless steel water connection:
• Long life even in less than perfect water conditions
• Seals water and air chambers ensuring a complete leak free and maintenance free pressure vessel

Every tank is individually tested:
• Guaranteed reliable operation

Compliance with the strict requirements of ISO 9001, NSF Standard 61, CE/PED, WRAS, ACS, Watermark and Gost quality standards:
• Consistent product quality
• Assurance of acceptance by plumbing regulators

Available in:
24008P Supercell 8P 8 3 1000 kPa pipe 1"(M)
24018P Supercell 18P 18 6.7 1000 kPa pipe 1"(M)
24040P Supercell 40P 40 14.1 1000 kPa pipe 1"(M)
24060P Supercell 60P 60 21.2 1000 kPa free standing 1"(F)
24100P Supercell 100P 100 37.5 1000 kPa free standing 1"(F)

24200G Supercell 200G 200 75 1000 kPa free standing 11/4"(F)
24018PHP16 Supercell 18PHP16 18 6.7 1600 kPa pipe 1"(M)
24080PHP16 Supercell 80PHP16 80 28.2 1600 kPa free standing 1"(F)
24024HP25 Supercell 24HP25 24 9 2500 kPa pipe 1" (M)
24100HP25 Supercell 100HP25 100 37.5 2500 kPa free standing 1" (M)

Please contact us for latest pricing
