Underground Tanks

The new of horizontal SUB under water ground tanks are the ultimate in underground water management.
The SUB’s are light enough to be manhandled which is a major benefit when section access is limited and once installed the only part visible is a low profile childproof manhole cover. With 7 different length combinations and capacities ranging from 2,000 litres to 5,000 litres, the SUB’s suit almost all applications. But should more volume be required, it is a straightforward procedure to link multiple tanks together.
New development often places additional demands on stormwater systems, these systems may not have the capacity to handle further loads. Often in these situations a stormwater detention tank is the best solution. Stormwater detention tanks are designed to store rainwater from roofs, drives, paths and other impervious areas. The water is then discharged to the stormwater system from the tank through a small diameter orifice pipe at a rate the stormwater system can cope with.
The SUB’s are perfect for stormwater detention and make light work of council requirements. Each tank comes with preset connection points for inlets, outlets and overflows. It is a simple procedure to fit the specified orifice.

-Ribbed design for strength.
-Ultimate solution for stormwater retention.
-Multiple inlet and outlet positions.
-Wide foot for easy leveling.
-300mm deep sump.
-Integrated lifting points

SUB1050D.2000 Capacity 2,000l (2.0m2) L 2900mm W 1050mm
H (min/max) 1600 / 2000mm Weight 140kg
SUB1050D.2500 Capacity 2,500l (2.5m2) L 3600mm W 1050mm
H (min/max)1600 / 2000 Weight 165kg
SUB1050D.3000 Capacity 3,000l (3.0m2) L 4300mm W 1050mm
H (min/max) 1600 / 2000 Weight 190kg
SUB1050D.3500 Capacity 3,500l (3.5m2) L 5000mm W 1050mm
H (min/max) 1600 / 2000 Weight 215 kg
SUB1050D.4000 Capacity 4,000l (4.0m2) L 5700mm W 1050mm
H (min/max) 1600 / 2000 Weight 240kg
SUB1050D.4500 Capacity 4,500l (4.5m2) L 6400mm W 1050mm
H (min/max) 1600 / 2000 Weight 265kg
SUB1050D.5000 Capacity 5,000l (5.0m2) L 7100mm W 1050mm
H (min/max) 1600 / 2000 Weight 290 kg
