Rinnai Boil & Brew Automatic Boiling Water Units

Rinnai Boil & Brew Automatic Boiling Water Unit

The British take tea, Americans have a coffee break, but for we Kiwis, it will always be smoko.
When the time comes, we put aside our work, grab our favourite mug and gather at the Boil & Brew with our tea bags and instant at the ready. For the next 15 minutes we dunk our biscuits and talk about our weekends, the rugby and what’s on the telly.
Made right here in New Zealand, with a new modern look and a number of improvements we know there are going to be many more smokos and great yarns around our new Rinnai Boil & Brew

Range of sizes

The Boil and Brew is available in 5L, 10L, 15L and 25L with a delivery from 35–200 cups an hour. They are ideal for any space that necessitates an endless supply of boiling water such as commercial kitchens, staff rooms and hospitals.

Automatic operation

The Rinnai Boil & Brew units are completely automatic, re-filling and heating as water is drawn off.

Convenience

No more waiting for the kettle to boil—boiling water when you need it for tea, coffee, other hot drinks or convenience foods.

Easy clean

Attractive powder coat white case allows for easy cleaning of the unit.

Suitable as a hot water dispenser for commercial applications such as; cafes, canteens, retirement homes, restaurants, hotels, hospitals, schools, sports complexes, factories, fast food outlets, shops, and offices.

Connections
Inlet and overflow connections, R15 (½ " BSP). Stop tap and union not supplied.

For concealed plumbing connections installer to install two R15 (½ " BSP) female wing back, tee or elbows to the lower right hand corner of the dispenser mounting position.

Data plate
Cover off—middle of back panel. This label will have the serial number.

Hot water delivery* (approx. 6 cups per litre)
- 5 L   = 35 cups
- 10 L = 100 cups
- 15 L = 130 cups
- 25 L = 200 cups

* standard teacup is approx. 170 mls at greater than 65 °C

Element size and Amp rating
- 5 L   = 2.0 kW (10 A)
- 10 L = 2.4 kW (10 A)
- 15 L  = 2.4 kW (10 A)
- 25 L = 3.0 kW (15 A)

Electrical supply
5 L, 10 L, 15 L comes with a 2 m cord. 25 L is a fixed wired unit. Voltage rating 230/240 V 50 Hz AC, single phase.
Water supply pressure
Minimum 87 kPa, maximum 1000 kPa.
Thermostats
Electronic to control water temperature to boiling point.
Construction
Outer casing white powder coated steel, thermal insulation 40 mm fibreglass, and copper water container.
Safety devices
Automatic thermostat, temperature override, water level control, and water overflow protection.
Protection against water
IPXO
Approx. nominal commissioning times from cold (mins. to ready)
- 5 L   = 14 minutes
- 10 L = 23 minutes
- 15 L  = 30 minutes
- 25 L = 50 minutes

Weights: empty and full
- 5 L   = 7 kg / 12 kg
- 10 L = 9 kg / 19 kg
- 15 L  = 10 kg / 25 kg
- 25 L = 12 kg / 37 kg

PRICE: Contact us for pricing on the Rinnai Boil & Brew Range

The Boil and Brew is available in 5L, 10L, 15L and 25L
